JG150L heavy-duty crawler-type excavator with straight boom and quadrilateral design
Brand :JINGGONG
Product origin :CHINA
Delivery time :30DAYS
Supply capacity :5000UNITS
The JG150L Heavy-Duty Tracked Excavator revolutionizes deep digging operations with its robust direct-arm structure and innovative four-flange system, ensuring superior digging force and stability in challenging terrains. Its full-track undercarriage provides unmatched traction on soft or uneven ground, minimizing slippage and boosting efficiency for tasks like foundation work or trenching. Engineered for longevity, the excavator features heavy-duty components with enhanced wear resistance, reducing maintenance needs and downtime. User-friendly controls and a modular design simplify operation and servicing, making it an ideal choice for construction and mining professionals seeking reliable, high-performance equipment that maximizes productivity with minimal effort.
Jg150Z Crane Grabber Loading Scrap Handler Orange Grab Bucket Grapple Excavator
| SPECIFICATIONS | ||||||||||
| RANGE OF OPERATION | Boom length | 4200mm | ||||||||
| Arm length | 2000mm | |||||||||
| Maximum Digging Reach | 7200mm | |||||||||
| Maximum Digging Depth | 4100mm | |||||||||
| Maximum Digging Force | 90KN | |||||||||
| Maximum Digging Height | 8000mm | |||||||||
| Maximum Dumping Height | 6000mm | |||||||||
| Back-end radius of gyration | 2250mm | |||||||||
| DIMENSION | (Length*width*height) Transport Dimensions | 7200*2500*3000mm | ||||||||
| Wheel base | 2750mm | |||||||||
| Track(Front/rear) | 1900mm | |||||||||
| Ground clearance of counterweight | 1260mm | |||||||||
| Min ground clearance | 310mm | |||||||||
| DIMENSION OF GRAPPLE | Angle of rotation | 360° | ||||||||
| Weight of Grab | 700kg | |||||||||
| Max. Opening Width of Grab | 1600mm | |||||||||
| Min. Opening Width of Grab | 150mm | |||||||||
| Closing Height | 1700mm | |||||||||
| Maximum Dumping Height | 5300mm | |||||||||
| Farthest Grabing Distance | 7500mm | |||||||||
| TECHNICAL PARAMETERS | Angle of rotation | 360° | ||||||||
| Machine weight | 12500kg | |||||||||
| Engine model | Cummins | |||||||||
| Rated Power | 93KW | |||||||||
| Rated Speed | 2200r/min | |||||||||
| Hydraulic system working pressure | 28Mpa | |||||||||
| Hydraulic system flow | 270L/min | |||||||||
| Variable piston pump | 2*63ml/r | |||||||||
| Max Hauling force | 76.5KN | |||||||||
| Walking speed | 25km/h | |||||||||
| Grade Climbing ability | 58%/30° | |||||||||
| Tyre model | 9.00-20 | |||||||||
| Volume Of Bucket | 0.4-0.5m3 | |||||||||
| Fqt Fuel Quantity | ≥8L/h | |||||||||
| Hydraulic Tank Capacity | 200L | |||||||||
| Capacity Of The Fuel Tank | 200L | |||||||||
